CNC-YF-7-60 Automatic 3D Wire Bending Machine

CNC-YF-7-60 Automatic 3D Wire Bending Machine

CNC-YF-7-60 Automatic 3D Wire Bending Machine

The lifting platform ensures stability when bending long wire materials into shaped products.
The bending mechanism accommodates bends at different R positions, with a large forming space suitable for the production of long products.
Three sets of wire-feeding wheels ensure a wire-feeding accuracy of ±0.1mm within a range of 280mm.
Seven sets of straighteners in both longitudinal and transverse directions ensure the straightness of wire feeding.
The CNC system supports multiple languages, making it easy to learn and operate.
The wire winding reel straightens the wire materials, facilitating stable and effortless production.
Safety protective cover.

Specification

Technical Parameters
Model YF-7-60 Wire~switching shaft servo power 1.2KW
Wire diameter Φ2.0mm-Φ6.0mm Φ 2mm- Φ6mm iron wire Torsion shaft servo power 1.2KW
Axles number 7 axles Lifting platform servo power 0.75KW
Wire feed length Infinite Cut shaft servo motor 0.75KW
Wire feed speed 100Meter/MIn Torsion lifting platform servo power 0.75KW
Wire Feed instruction value ±0.01-±9999.99 Core-switching shaft servo power 1.2KW
Cam instruction value ±0.1°-±359.9° Machine weight 2000KG
Wire feed shaft servo power 2.7KW Machine sizes 2950×1750×1500

Explanation

Advantages:
computer startup, shutdown speed is fast, simple, and convenient to operate, supports multi-language operation, the computer interface can adjust the speed and change the program at the same time of production;
the configuration of the use of imported high-precision high-speed servo motor, imported reducer, stable and durable production speed is more than 30% higher than the domestic counterparts of the same kind of products;
The production process can achieve no change in the Angle when the Angle is folded at different speeds, and the production stability is better;
Bearings, gear, and other important parts of the imported parts, 9125 hours of warranty, durable and reliable equipment;
High precision, can be made within the range of 2.0-14 mm wire diameter wire molding products, the error is reduced to 0.1mm;
good after-sales service system: provide technical training support free of charge! Equipment lifetime maintenance.

Product Details:
Advanced Wire Manipulation Technology:
At the heart of this machine lies its sophisticated 3D wire-bending technology. Capable of handling wire diameters ranging from Φ2.0mm to Φ6.0mm, it empowers users to create intricate wire structures with ease. Whether crafting prototypes or mass-producing components, the Automatic 3D Wire Bending Machine delivers versatility and accuracy.
Diversified 3D Molding:
One of the standout features of this machine is its ability to execute diverse 3D molding tasks. From simple curves to complex geometries, it offers unmatched flexibility in shaping wire materials to meet varying specifications. Whether it's crafting customized designs or replicating existing models, this machine excels in delivering precise results across a spectrum of applications.
High Automatization and Intellectualization:
Equipped with advanced automation and intelligent controls, this machine operates at peak efficiency while reducing manual intervention. Its intuitive interface streamlines the production process, allowing operators to effortlessly program and execute bending tasks. By leveraging advanced algorithms and sensor technologies, it ensures consistent performance and quality output with less downtime.

Maintenance:
Correct installation and placement
After the machine is placed in the workshop, the need for sufficient ground grounding, manufacturers in the process of transportation, there is a board at the bottom, the need to take the board off, pad rubber pad, the purpose of this is to prevent wire molding machine production process, not due to the machine running vibration.
Add oil and butter regularly.
Refueling position is mainly curly, wire box, transmission gear, and other places, long-term maintenance of the wire forming machine part of the running in place of oil lubrication, generally a week to check the butter.
Keep the machine clean.
Every day before work, the staff need to clean the surface of the wire-forming machine. If it is not cleaned for a long time and oil accumulates, there will be the possibility of changing the circuit parameters, and long-term erosion of dust, so that the machine surface aging, affecting its appearance.
Normal operation and use
Special care should be taken not to produce products beyond the line diameter range, so as not to reduce the accuracy of the equipment. The machine should be placed in a ventilated and dry place to prevent moisture from rusting or damaging the circuit. Can achieve timely and careful maintenance of the machine, can maintain the precision and stability of the wire molding machine, extend the service life, and also can reduce the repair rate of the machine.
